100"-200" Motorized Rollable Projector Screen

Overview & Features SPECS Screen Materials GALLERY FAQs

SCREENPRO projector screen in a classroom

SCREENPRO motorized screen in a meeting room

The Most Suitable Option

Matte White | White Micro-Perforated | Woven Acoustically Transparent

Enjoy your private cinema with your family and friends. Black backing eliminates light penetration for enhanced brightness and color reproduction(matte white material option), or you can place speakers directly behind the screen without dampening high-performance sound quality (perforated | woven material option). These options are for applications where you have control over ambient light.

SCREENPRO tab motorized screen viewing angle

Rollable Design for Home Theater

Enjoy dynamic, colorful media without losing valuable wall space with its rollable design.

Power Consumption
In the working state: less than 120W
In standby mode: less than 1W

SCREENPRO motorized screen in different housing

Simple and Elegant

-Aluminum case with adjustable mounting brackets for wall or ceiling mount installation on sizes over 19’wide. Developed by the Chinese and European engineering co-team. Glorious white baking paint process, fully enclosed lower bar, which has the function of dust prevention.

SCREENPRO motorized screen rechargeable remote

R8 Control System

SCREENPRO® R&D R8 control system, with rechargeable(micro-B port) RF (Radio Frequency) remote control, built-in low-power, high-performance, long-distance 868MHz wireless data transmission module, and easy to operate. (Crestron control system compatible)

SCREENPRO motorized screen surface tension adjustment

Flatness

Screen flatness affects the resolution in your projection. The tab-tensioning system will keep the projection surface under constant tension for a perfectly flat viewing area. A flat projection surface will get the most out of your projector, making sure no pixels get lost or deformed. If the detail is important, a perfectly flat projection area is vital. The tab-tension configuration keeps the screen flat and taut, preventing screen curling; the black backing eliminates light penetration to avoid picture degradation

SCREENPRO motorized screen slidable track

Easy Installation

Each screen features a full kit for installation right out of the box. SCREENPRO® offers brackets that allow both wall and ceiling installations, which also feature horizontal adjustment, making it easy to target when you have an attic or a crawl space above the screen housing.

inside of SCREENPRO motorized screen with motor

Installation

SCREENPRO JAMPO series supports 3 installation methods to meet different needs(suspension | on the ceiling | on the wall)

SCREENPRO screen synchronized by projector trigger

Synchronizer

Multiple control methods, sync your projector(sync-trigger), and make your home smart the way you like.

*(add-on option)Synchronizer only works for the SCREENPRO^® motorized screen series

SELECT THE RIGHT SCREEN FOR YOUR SPACE

At SCREENPRO, we’re proud of our wide selection of high-quality projection screens. To help you quickly find the right screen model with the right technical capabilities for your Home Theater project, please refer to the chart below.

Just like televisions, projector screens are measured in imperial feet and inches. The screen is measured by the width of the material from left to right. The viewable area is the white part of the screen which is slightly smaller due to the surrounding black borders.

Straight

SCREENPRO Tensioned Screen - Jampo																									Unit: mm
FORMAT	DIAG.SIZE		VIEWING SIZE			BLACK BORDER															Ceiling cut out size (LxWxD)			NOTE	APPROX. WEIGHT
FORMAT	DIAG.SIZE		VIEWING SIZE			Top	Bottom	(L/R)	SCREEN OVERALL LENGTH	SCREEN OVERALL HEIGHT	PACKAGE DIMENSIONS					WOODEN CRATE PACKAGING					CEILING SLOT DIMENSION			NOTE	APPROX. WEIGHT
	D		W	x	H	B1	B2	A	L	B	W1	X	H1	X	L1	W2	X	H2	X	L2	P2	H2	W2	Section Size	Kg
16:9	92	˝	2037	X	1146	400	50	60	2360	1717	230	X	185	X	2410	250	X	335	X	2460	2460	150	130	Jampo 96x88mm	20.7
	100	˝	2214	X	1245	400	50	60	2537	1816	230	X	185	X	2587	250	X	335	X	2637	2637	150	130		22.3
	106	˝	2346	X	1320	400	50	60	2669	1891	230	X	185	X	2719	250	X	335	X	2769	2769	150	130		23.4
	110	˝	2435	X	1370	400	50	60	2758	1941	230	X	185	X	2808	250	X	335	X	2858	2858	150	130		24.2
	120	˝	2656	X	1494	400	50	60	2959	2065	230	X	185	X	2970	250	X	335	X	3020	3059	150	130		26.1
	135	˝	2988	X	1681	400	50	60	3311	2252	230	X	185	X	3361	250	X	335	X	3411	3411	150	130		29.2
	150	˝	3320	X	1868	400	50	60	3672	2498	250	X	250	X	3772	270	X	400	X	3822	3772	195	195	Jampo L 150X150mm	46.2
	165	˝	3652	X	2055	400	50	60	4004	2685	250	X	250	X	4104	270	X	400	X	4154	4104	195	195		51.3
	180	˝	3984	X	2241	400	50	60	4336	2871	250	X	250	X	4436	270	X	400	X	4486	4436	195	195		56.6
	200	˝	4427	X	2490	200	50	60	4779	2920	250	X	250	X	4879	270	X	400	X	4929	4879	195	195		75.5
	220	˝	4870	X	2739	200	50	60	5222	3169	250	X	250	X	5322	270	X	400	X	5372	5322	195	195		83.8
	240	˝	5313	X	2988	200	50	60	5665	3418	250	X	250	X	5765	270	X	400	X	5815	5765	195	195		92.0
	250	˝	5534	X	3113	200	50	60	5886	3543	250	X	250	X	5986	270	X	400	X	6036	5986	195	195		97.0
16:10	92	˝	1982	X	1239	400	50	60	2305	1810	230	X	185	X	2355	250	X	335	X	2405	2405	150	130	Jampo 96x88mm	20.7
	100	˝	2154	X	1346	400	50	60	2477	1917	230	X	185	X	2527	250	X	335	X	2577	2577	150	130		22.0
	106	˝	2283	X	1427	400	50	60	2606	1998	230	X	185	X	2656	250	X	335	X	2706	2706	150	130		23.4
	110	˝	2369	X	1481	400	50	60	2692	2052	230	X	185	X	2742	250	X	335	X	2792	2792	150	130		24.2
	120	˝	2585	X	1615	400	50	60	2908	2186	230	X	185	X	2958	250	X	335	X	3008	3008	150	130		26.2
	135	˝	2908	X	1817	400	50	60	3231	2388	230	X	185	X	3281	250	X	335	X	3331	3331	150	130		29.3
	150	˝	3231	X	2019	400	50	60	3583	2649	250	X	250	X	3683	270	X	400	X	3733	3683	195	195	Jampo L 150X150mm	45.5
	165	˝	3554	X	2221	400	50	60	3906	2851	250	X	250	X	4006	270	X	400	X	4056	4006	195	195		49.7
	180	˝	3877	X	2423	300	50	60	4229	2953	250	X	250	X	4329	270	X	400	X	4379	4329	195	195		53.9
	200	˝	4308	X	2692	200	50	60	4660	3122	250	X	250	X	4760	270	X	400	X	4810	4760	195	195		71.1
	220	˝	4739	X	2962	200	50	60	5091	3392	250	X	250	X	5191	270	X	400	X	5241	5191	195	195		78.0
	250	˝	5385	X	3366	200	50	60	5737	3796	250	X	250	X	5837	270	X	400	X	5887	5837	195	195		88.7
	257	˝	5536	X	3460	200	50	30	5828	3890	250	X	250	X	5928	270	X	400	X	5978	5928	195	195		91.2
2.35:1	96	˝	2244	X	955	600	50	60	2567	1726	230	X	185	X	2617	250	X	335	X	2667	2667	150	130	Jampo 96x88mm	22.5
	100	˝	2337	X	995	550	50	60	2660	1716	230	X	185	X	2710	250	X	335	X	2760	2760	150	130		23.2
	106	˝	2478	X	1054	550	50	60	2801	1775	230	X	185	X	2851	250	X	335	X	2901	2901	150	130		24.5
	119	˝	2781	X	1184	500	50	60	3104	1855	230	X	185	X	3154	250	X	335	X	3204	3204	150	130		27.1
	126	˝	2945	X	1253	500	50	60	3268	1924	230	X	185	X	3318	250	X	335	X	3368	3368	150	130		28.5
	135	˝	3155	X	1343	400	50	60	3507	1973	250	X	250	X	3607	270	X	400	X	3657	3607	195	195	Jampo L 150X150mm	43.3
	150	˝	3506	X	1492	400	50	60	3858	2122	250	X	250	X	3958	270	X	400	X	4008	3958	195	195		47.6
	159	˝	3716	X	1581	400	50	60	4068	2211	250	X	250	X	4168	270	X	400	X	4218	4168	195	195		50.1
	165	˝	3857	X	1641	400	50	60	4209	2271	250	X	250	X	4309	270	X	400	X	4359	4309	195	195		51.8
	180	˝	4207	X	1790	400	50	60	4559	2420	250	X	250	X	4659	270	X	400	X	4709	4659	195	195		67.6
	200	˝	4675	X	1989	400	50	60	5027	2619	250	X	250	X	5127	270	X	400	X	5177	5127	195	195		74.5
	220	˝	5142	X	2188	400	50	60	5494	2818	250	X	250	X	5594	270	X	400	X	5644	5594	195	195		81.7

Arc

SCREENPRO Tab Tensioned Screen - Jampo																									Unit: mm
FORMAT	DIAG.SIZE		VIEWING SIZE			BLACK BORDER															Ceiling cut out size (LxWxD)			NOTE	APPROX. WEIGHT
FORMAT	DIAG.SIZE		VIEWING SIZE			Top	Bottom	(L/R)	SCREEN OVERALL LENGTH	SCREEN OVERALL HEIGHT	PACKAGE DIMENSIONS					WOODEN CRATE PACKAGING					CEILING SLOT DIMENSION			NOTE	APPROX. WEIGHT
	D		W	x	H	B1	B2	A	L	B	W1	X	H1	X	L1	W2	X	H2	X	L2	P2	H2	W2	Section Size	Kg
16:9	84	˝	1859	X	1046	600	50	60	2282	1817	230	X	185	X	2332	250	X	335	X	2382	2382	150	130	Jampo 96x88mm	19.0
	92	˝	2037	X	1146	500	50	60	2460	1817	230	X	185	X	2510	250	X	335	X	2560	2560	150	130		22.2
	100	˝	2214	X	1245	400	50	60	2637	1816	230	X	185	X	2687	250	X	335	X	2737	2737	150	130		23.7
	106	˝	2346	X	1320	400	50	60	2769	1891	230	X	185	X	2819	250	X	335	X	2869	2869	150	130		24.8
	110	˝	2435	X	1370	400	50	60	2858	1941	230	X	185	X	2908	250	X	335	X	2958	2958	150	130		25.5
	120	˝	2656	X	1494	400	50	60	3079	2065	230	X	185	X	3129	250	X	335	X	3179	3179	150	130		27.4
	135	˝	2988	X	1681	400	50	60	3411	2252	230	X	185	X	3461	250	X	335	X	3511	3511	150	130		30.6
	150	˝	3320	X	1868	400	50	60	3772	2498	250	X	250	X	3872	270	X	400	X	3922	3872	195	195	Jampo L 150X150mm	48.6
	165	˝	3652	X	2055	400	50	60	4104	2685	250	X	250	X	4204	270	X	400	X	4254	4204	195	195		52.8
	180	˝	3984	X	2241	400	50	60	4476	2871	250	X	250	X	4576	270	X	400	X	4626	4576	195	195		57.1
	200	˝	4427	X	2490	200	50	60	4919	2920	250	X	250	X	5019	270	X	400	X	5069	5019	195	195		75.0
	220	˝	4870	X	2739	200	50	60	5362	3169	250	X	250	X	5462	270	X	400	X	5512	5462	195	195		82.1
	250	˝	5534	X	3113	200	50	60	6026	3543	250	X	250	X	6126	270	X	400	X	6176	6126	195	195		92.9
16:10	92	˝	1982	X	1239	400	50	60	2405	1810	230	X	185	X	2455	250	X	335	X	2505	2505	150	130	Jampo 96x88mm	21.8
	100	˝	2154	X	1346	400	50	60	2577	1917	230	X	185	X	2627	250	X	335	X	2677	2677	150	130		23.2
	106	˝	2283	X	1427	400	50	60	2706	1998	230	X	185	X	2756	250	X	335	X	2806	2806	150	130		24.3
	110	˝	2369	X	1481	400	50	60	2792	2052	230	X	185	X	2842	250	X	335	X	2892	2892	150	130		25.2
	120	˝	2585	X	1615	400	50	60	3008	2186	230	X	185	X	3058	250	X	335	X	3108	3108	150	130		27.1
	135	˝	2908	X	1817	400	50	60	3331	2388	230	X	185	X	3381	250	X	335	X	3431	3431	150	130		30.2
	150	˝	3231	X	2019	400	50	60	3683	2649	250	X	250	X	3783	270	X	400	X	3833	3783	195	195	Jampo L 150X150mm	47.7
	165	˝	3554	X	2221	400	50	60	4006	2851	250	X	250	X	4106	270	X	400	X	4156	4106	195	195		52.0
	180	˝	3877	X	2423	300	50	60	4369	2953	250	X	250	X	4469	270	X	400	X	4519	4469	195	195		56.1
	200	˝	4308	X	2692	200	50	60	4800	3122	250	X	250	X	4900	270	X	400	X	4950	4900	195	195		74.0
	220	˝	4739	X	2962	200	50	60	5231	3392	250	X	250	X	5331	270	X	400	X	5381	5331	195	195		80.8
	250	˝	5385	X	3366	200	50	60	5877	3796	250	X	250	X	5977	270	X	400	X	6027	5977	195	195		91.5
	257	˝	5536	X	3460	200	50	30	5968	3890	250	X	250	X	6068	270	X	400	X	6118	6068	195	195		94.0
2.35:1	96	˝	2244	X	955	600	50	60	2667	1726	230	X	185	X	2717	250	X	335	X	2767	2767	150	130	Jampo 96x88mm	23.7
	100	˝	2337	X	995	550	50	60	2760	1716	230	X	185	X	2810	250	X	335	X	2860	2860	150	130		24.5
	106	˝	2478	X	1054	550	50	60	2901	1775	230	X	185	X	2951	250	X	335	X	3001	3001	150	130		25.6
	119	˝	2781	X	1184	500	50	60	3204	1855	230	X	185	X	3254	250	X	335	X	3304	3304	150	130		28.3
	126	˝	2945	X	1253	500	50	60	3368	1924	230	X	185	X	3418	250	X	335	X	3468	3468	150	130		29.7
	135	˝	3155	X	1343	400	50	60	3607	1973	250	X	250	X	3707	270	X	400	X	3757	3707	195	195	Jampo L 150X150mm	45.4
	150	˝	3506	X	1492	400	50	60	3958	2122	250	X	250	X	4058	270	X	400	X	4108	4058	195	195		49.7
	159	˝	3716	X	1581	400	50	60	4168	2211	250	X	250	X	4268	270	X	400	X	4318	4268	195	195		52.3
	165	˝	3857	X	1641	400	50	60	4309	2271	250	X	250	X	4409	270	X	400	X	4459	4409	195	195		53.9
	180	˝	4207	X	1790	400	50	60	4699	2420	250	X	250	X	4799	270	X	400	X	4849	4799	195	195		70.4
	200	˝	4675	X	1989	400	50	60	5167	2619	250	X	250	X	5267	270	X	400	X	5317	5267	195	195		77.2
	220	˝	5142	X	2188	400	50	60	5634	2818	250	X	250	X	5734	270	X	400	X	5784	5734	195	195		84.4

calculator

More Screen Material Options In This Series

Gain ｜ Viewing angle ｜ Resolution

1.0 156° 4K

Learn more »

Gain ｜ Viewing angle ｜ Diameter

0.95 165° ∅0.2mm

Learn more »

Gain ｜ ALR ｜ Viewing angle

1.1 70% 160°

Learn more »

Gain ｜ ALR ｜Viewing angle

1.1 90% 140°

Learn more »

Gain ｜ ALR ｜ Resolution

1.0 90% 4K

Learn more »

7mm Frame Acoustic Transparency Screen - FZ

Frame

Aluminum

Bezel Size

7mm(0.3

Color Options

Black

Available Sizes

100

LED Backlight Kit

Optional

Pre-Assembled

Installation

Wall Mount

Can I choose an ALR material such as fabric SP/8K/T8 for my Quick-Fold series screen?

Sadly, it can not match the quick-fold series. Folding the screen may create creases in the material.

Can I purchase a small sample of the material?

Yes, you can buy a screen material sample by clicking HERE.

What is the voltage for the SCREEN PRO motorized series? Can it be used abroad?

110v / 220v. No power transformer is required. We ensure that the voltage is correct for your shipping address.

How many types of projection screens do you produce?

SCREENPRO® mainly produces motorized projection screens, tensioned projection screens, fixed-frame screens, portable folding screens, large-sized stage projection screens, etc. Clicking HERE.

Can I customize the screen size?

Yes, the size can be customized from 60 inches to 500 inches plus. Clicking HERE.

What are your specialties?

Projection Screens, Motorized Solutions, Theatre Supplies, Projection Systems, Audiovisual Accessories, ALR UST screens, Electric screens, Manual screens, Mobile screens, Fixed screens, In-ceiling screens, and Customizable.

What's your Mode of Transport?

A：Air Transport（By Air）
B：Water/Sea Transport（By Water/Sea）
C：Road/Truck Transport（By Road/Truck）
D：Rail Transport（By Rail）
E：Mail Transport（By Mail）
F：Other Transport

Usually, we ship by DHL in HK, but considering the inconsistent shipping fees in different countries, we will ship by FedEx, UPS, TNT, etc...

Airline and Ocean transportation; You can choose the shipping way you prefer. HERE.
