Large Venue Motorized Projector Screen - TT

Giant Electric Roller Screen

  • Designed for large-stage performance
  • Multiple projection material for environments with dark/minimum light source
  • White powder-coated finish with tensioned surface design
  • Rear projection surfaces available (visit Material for more viewing surface information)
  • Aluminum housing complete with low noise retraction
  • External/RF remote control operation
  • Support third-party control system
  • For suspending or ceiling mounting






Overview & Features SPECS Screen Materials GALLERY FAQs

Superb Large Size

Rollable Design For Better Performance


Base from 600 cm up to 900 cm. Aluminum case dimensions: 8.27" high x 8.27" deep (210cm x 210 cm), which allows a widescreen size range, so the audience can enjoy the dynamic, colorful images.
Applicable: Worship | Theatre | Museum | Auditoriums | Lecture Hall | Ballroom | Boardroom | Cinema

Bigger Performance

Grand Image

Elegant smooth aluminum housing developed by Chinese and European engineers co-team. Glorious white powder-coated finish fully enclosed lower bar which has the function of dust prevention. Designed for large occasions, project a huge picture.

Invisible Ceiling Mounting Brackets

Slidable bracket point-to-point installation moves freely features of this exclusive product. Available in a wide range of different projection materials, enabling you to customize the finished screen to meet your customers’ requirements.



LATEST VIDEOS | LATEST PROJECT NEWS



Intelligent Control System

SCREENPRO® R&D R8 control system, built-in 868MHz wireless remote control, easy to operate. Low voltage contact interface, supports most common connections, such as: DC AMC, and Sync-trigger, easy to wire to the integrated media center.

Flatness

Screen flatness affects the resolution in your projection. The tab-tensioning system will keep the projection surface under constant tension for a perfectly flat viewing area. A flat projection surface will get the most out of your projector, making sure no pixels get lost or deformed. If the detail is important a perfectly flat projection area is vital.

Easy Maintenance

Separate detachable inner axis for easy maintenance or motor replacement. Fast and quiet motor (Nm 9 – Rpm 26)



Synchronizer

Sync your projector(sync-trigger), and make your home smart the way you like. A small universal device that can synchronize your projector on and off along with the screen surface going down and up. No need to consider with or without the trigger port.



〈 WATCH THE INSTALLATION VIDEO?



SELECT THE RIGHT SCREEN FOR YOUR SPACE

At SCREENPRO, we’re proud of our wide selection of high-quality projection screens. To help you quickly find the right screen model with the right technical capabilities for your Home Theater project, please refer to the chart below.

Customized larger size? Please Contact Us



SCREENPRO Large Venue Tensioned Screen - Topview
FORMAT DIAG.SIZE VIEWING SIZE BLACK BORDER
Top Bottom (L/R) SCREEN OVERALL LENGTH SCREEN OVERALL HEIGHT WOODEN CRATE PACKAGING NOTE
  D WxH B1 B2 A L B L2 Section Size
16:9 260˝ 5755x3237 200 50 75 6173 3747 305x435x6360 Topview
280˝ 6198x3486 200 50 75 6653 4086 380x560x6850 Topview Plus
328*280
300˝ 6640x3735 200 50 75 7096 4335 380x560x7290
350˝ 7747x4358 200 50 75 8203 4958 380x560x8390
400˝ 8854x4980 200 50 75 9309 5581 380x560x9500
16:10 270˝ 5815x3634 200 50 75 6234 4145 305x435x6420 Topview
280˝ 6030x3769 200 50 75 6486 4369 380x560x6675 Topview Plus
328*280
300˝ 6461x4038 200 50 75 6917 4639 380x560x7110
350˝ 7538x4711 200 50 75 7994 5312 380x560x8185
400˝ 8615x5384 200 50 75 9071 5985 380x560x9260
420˝ 9046x5654 200 50 75 9501 6254 380x560x9690
2.35:1 250˝ 5843x2486 200 50 75 6298 3086 380x560x6490 Topview Plus
328*280
280˝ 6544x2784 200 50 75 6999 3385 380x560x7190
300˝ 7011x2983 200 50 75 7467 3584 380x560x7660
350˝ 8180x3481 200 50 75 8636 4081 380x560x8830
380˝ 8881x3779 200 50 75 9337 4379 380x560x9530





calculator



More Screen Material Options In This Series







MW

Gain | Viewing angle | Resolution

 1.0              156°                   4K

 Learn more »








TM

Gain | Viewing angle | Diameter

0.95           165°             ∅0.2mm

Learn more »








 8K

Gain | ALR | Viewing angle

1.1          70%           160°

Learn more »








T8

Gain | ALR |Viewing angle

 1.1         90%        140°

Learn more »






RL

Gain | ALR | Resolution

1.0       90%           4K

   Learn more »








Actual product may vary from image shown.
Product specifications subject to change without notice.

Acoustic Transparency Fixed Frame - FP
Acoustic Transparency Fixed Frame - FP
Acoustic Transparency Fixed Frame - FP
Frame
Aluminum
Aluminum
Aluminum
Bezel Size
60/90/120mm(2.3)
60/90/120mm(2.3)
60/90/120mm(2.3)
Color Options
Velvet | Wood Grain
Velvet | Wood Grain
Velvet | Wood Grain
Available Sizes
Up To 400”
Up To 400”
Up To 400”
LED Backlight Kit
N/A
N/A
N/A
Pre-Assembled
×
×
×
Installation
Wall Mount
Wall Mount
Wall Mount

Can I buy a small screen material sample?

Yes, you can buy a screen material sample by clicking Yes, you can buy a screen material sample by clicking HERE.

How many types of projection screens do you produce?

Our factory mainly produces motorized projection screen, tensioned projection screen, fixed frame screen, folding screen, big size projection screen, etc. HERE.

Can I customize the size?

Yes, the size can be customized from 60 inches to 500 inches plus. HERE.

Do all types of projection screens have a warranty&How long do you offer for after-sales services?

12 months, for all types of the projection screen and we do provide lifetime maintenance, but you bear all cost.quipment, we will give you the right plug. HERE.

What's your shipping way?

Usually, we ship by DHL in HK, but considering the inconsistent shipping fee in different countries, we will ship byFedEx, UPS, TNT, etc...

Airline and Ocean transportation; You can choose the shipping way you prefer. HERE.

×
