Self-Rising ALR Screen - AD

Tab-Tensioned Screen for Ultra Short Throw Projectors

[Motorized self-rising ALR screen series]

  • Front projection T-Prism optical material, for environments with high ambient light
  • Deliver exceptionally clear images even in brightly lit surroundings
  • Low noise retraction
  • IR/RF remote control operation
  • Optional on wall bracket
  • Available screen size Max: 150” (130.7" x 73.5") in 16:9
  • Designed for ultra or short-throw projectors. Project within a short distance without shadowing the picture



SCREENPRO sales service

overview & Features SPECS SCREEN MATERIALS GALLERY FAQs

SCREENPRO floor rising screen in different ratioSCREENPRO floor rising screen in different ratio

SCREENPRO floor rising screen in front of window

Unboxing to operate. No need to install it, you can move it at will. It supports floor mount style, hidden in a variety of display ways, with no more holes in the wall.

SCREENPRO projection screen under light environment

A new way to open your private home theater.

Say NO to a messy wiring outlet on your ceiling, or have long runs of HDMI cables from your sources to the projector.

SCREENPRO motorized floor rising screen

If you don't want a fixed frame screen or ceiling mount electric screen, then the Electric ALR floor screen will be the ideal option.

Projector triggered motorized screen rolling down

The R8 control system was independently developed by SCREENPRO®. Equipped with 868MHz remote control (internal infrared and radio frequency receivers with IR/RF remotes included), which is convenient and fast to operate and supports limit adjustment. Standard projector trigger to synchronize screen operation with the projector's power cycle.

SCREENPRO ALR screen features description

The use of infrared automatic induction, anti-clamping hand device, in the process of closing and closing in case of obstacles, automatic stop, safe and reliable.

SCREENPRO ALR screen front and back

Ground-rising structure coordinates with silent tubular motor drives a double v-shaped structure bracket, with uniform force, to avoid stretching deformation of the fabric. The quiet tubular motor, which is with UL, CE, and 3C certification passed, operates smoothly with low noise.

SCREENPRO projector screen material sample

Looking for a screen

material sample

(A4 size) to try on?


SHOP NOW




SELECT THE RIGHT SCREEN FOR YOUR SPACE

At SCREENPRO, we're proud of our wide selection of high-quality projection screens.

To help you quickly find the right screen model with the right technical capabilities for your Home Theater project, please refer to the chart below.



FORMAT DIAG.SIZE VIEWING SIZE BLACK BORDER SCREEN OVERALL LENGTH SCREEN OVERALL HEIGHT PACKAGE DIMENSIONS WOODEN CRATE PACKAGING APPROX. WEIGHT
Top Bottom (L/R)
D WxH B1 B2 A L B L1xW1xH1   L2xW2xH2 Kg Lbs
16:9 92˝ 2037x1145 35 400 55 2272 1578 2332x235x235 2362x250x385 32 70
100˝ 2214x1245 35 400 55 2449 1680 2509x235x235 2539x250x385 33 73
110˝ 2435x1370 35 400 55 2670 1805 2730x235x235 2760x250x385 36 79
120˝ 2656x1494 35 400 55 2891 1929 2951x235x235 2981x250x385 38 84
135˝ 2988x1681 35 350 55 3223 2116 3283x235x235 3313x250x385 42 92
150˝ 3320x1868 35 300 55 3555 2253 3615x235x235 3645x250x385 46 100



NOTE:

L=housing length + power supply occupancy(≈70mm)
L-70mm = Housing Length



calculator






What is T-Prism?

SCREENPRO® T-Prism is an anti-light feature material, using a special trapezoidal optical physical structure, automatically separates the natural light and ultra-short-focus projector light, and absorbs ambient light on the light-absorbing surface by about 86% to achieve the ambient light rejection function. Using the multi-layer directional coating technology of the reflective surface, the projection screen contrast, color reproduction, gain ratio, and angle of view are optimally combined, and nearly 85% of the projector's light is reflected by the human eye so that the viewer can view it under natural light.
Watching the effect in a day and night environment, even in bright living rooms, it still presents 4K Ultra HD.





T-Prism Screen 4 Advantage

























Remarks:
1. The flameproof rating is determined according to the safety level of France NF P92-507.
2.
A. "A-washing refers to cleaning the screen surface with a solution of 7% ethanol and 3% ether."
B. "Clean the screen with kitchen detergent and water. Note that acidic detergents should not be used on any screen surface."

Cleaning Steps:
1. Use a soft brush to remove general dust from the screen surface.
2. Dip a soft cloth in mild soapy liquid or neutral detergent to clean the screen surface.
3. Avoid using rough objects or clothes as they may damage the screen surface.
4. The screen surface has optical textures, so please wipe horizontally when cleaning the fabric and avoid wiping vertically or in a circular motion.
5. Please ensure that the screen is completely dry after cleaning.

WARNING!
- To prevent puncturing or scratching the screen surface, please avoid direct contact with sharp objects.
- Do not use organic solvents such as acetone, benzene, or alcohol to clean the screen as they can cause permanent damage
- Please avoid scratching the screen surface to prevent any damage or distortion to the display.






Motorized ALR Screen - AJ
Motorized ALR Screen - AJ
Motorized ALR Screen - AJ
Application
Home Theater, Conference room etc.
Home Theater, Conference room etc.
Home Theater, Conference room etc.
Ceiling Projection
Installation
Suspending | Wall Mount | Ceiling Mount
Suspending | Wall Mount | Ceiling Mount
Suspending | Wall Mount | Ceiling Mount
Expansion Port
RS485/RS232、DC AMX
RS485/RS232、DC AMX
RS485/RS232、DC AMX
Control Options
868MHz RF remote
868MHz RF remote
868MHz RF remote
Limit Adjustment
Manually
Manually
Manually
Low Voltage Trigger
Optional
Optional
Optional
Motor
T Type Tubular Motor
T Type Tubular Motor
T Type Tubular Motor
Color Options
White | Black
White | Black
White | Black
Available Sizes
150
150
150
Housing
Aluminum
Aluminum
Aluminum

Can I buy a small screen material sample?

Yes, you can buy a screen material sample by clicking Yes, you can buy a screen material sample by clicking HERE.

How many types of projection screens do you produce?

Our factory mainly produces motorized projection screen, tensioned projection screen, fixed frame screen, folding screen, big size projection screen, etc. HERE.

Can I customize the size?

Yes, the size can be customized from 60 inches to 500 inches plus. HERE.

Do all types of projection screens have a warranty&How long do you offer for after-sales services?

12 months, for all types of the projection screen and we do provide lifetime maintenance, but you bear all cost.quipment, we will give you the right plug. HERE.

What's your shipping way?

Usually, we ship by DHL in HK, but considering the inconsistent shipping fee in different countries, we will ship byFedEx, UPS, TNT, etc...

Airline and Ocean transportation; You can choose the shipping way you prefer. HERE.

×
