7mm Frame ALR Screen For Long Throw Projector - FZ-8K

Thin Bezel Frame ALR Screen for Normal Throw Projectors

• Suggested throw ratio: >1.0
• Accompanied by: standard throw projector
• Aluminum lightweight split-frame design
• Material stretches over the frame for a permanently tight-tensioned flat surface
• Easy to assemble and install in minutes
• A smaller footprint maximizes the viewing area
• Optional edge-free or install ultra-thin trim
• Wall mount brackets slide, ensuring the frame is properly centred
• Optional LED backlight kit - sold separately

SCREENPRO screen sales warranty badge

Features Specifications Screen Material Gallery Compatible FAQs

How to Install SCREENPRO 100-inch ALR/CLR Projector Screen

Fixed frame screen with ALR feature

Stunning Visuals Any Time of Day

At SCREEN PRO, we offer an optical revolution that makes all the difference to your viewing experience, a technical improvement that results in a brighter, sharper image, and the ultimate viewing experience. SCREEN PRO ALR screen offers a beautifully designed frame screen, with a frame that only measures 7mm in width. It's designed to maximize your viewing experience while minimizing installation space.

compatible projector brand

Captivating 4K UHD Visuals

No more washed-out images, SCREEN PRO ALR screen designed for Long/Normal throw projectors, such as brand:
SAMSUNG | BenQ | Formovie | XIAOMI | Epson | Hitachi | LG | Optoma l Sony | ViewSonic etc…Enables compatibility with 8K resolution projectors

Projector material with layers inside

Why Choose ALR Screen

Unlike normal standard white fabric, the ALR screen carries vivid high-definition images regardless of ambient light; the optical material technology allows the display of true image brightness, color saturation, and contrast for superior picture performance.

Frame screen with

Classic Matte Black Profile Design

A metal frame that's stable, durable, and easy to maintain
Ultra-thin bezel enhances the aesthetics, and hand-wrapped black velvet is also possible, designed to maximize your viewing experience while minimizing installation space, giving the screen an even wider appearance. The outer layer of the screen is designed with anti-scratch material, which is easy to clean and maintain; the aluminum alloy frame makes the rollable screen flatter and more stable.

projection screen with frame

At One With Your Wall

The incredibly slim profile allows the screen to hang on your wall like a work of art, enhancing your home interior and adding elegance to your space. Double-layer frame structure makes borderless installation possible

frame screen with detailed

Hassle-free Installation



We strive for the best craftsmanship in each hand-built screen that we make. Simply unbox and follow the instructions, mount the projector screen to the wall enjoy your private theater in minutes.



WATCH THE INSTALLATION VIDEO 〉

SCREENPRO projector screen material sample

Looking for a screen

material sample

(A4 size) to try on?


SHOP NOW
SCREENPRO projector screen tensions adjustment

We Care, So You Don't Have To

We send packages overseas, making sure to securely wrap your screen to avoid it being damaged. The inner layer of the carton package is pearl cotton and a foam board buffer layer. Customized solid wood outer frame to ensure that the product is delivered to your home in good condition.
You can chill and relax waiting for it to show up at your door.

SCREENPRO Size Chart Pro Ultra

Select the Right Ultra-Thin Fixed Frame Screen

SCREENPRO Fixed Frame Screen - Ultra Thin is designed for dedicated cinema rooms, premium residential projects, commercial display spaces, and custom projection environments.

100"-150"Popular sizes for home theater and residential cinema projects.
160"-220"Recommended for larger rooms and wider viewing distances.
Ultra ThinClean fixed-frame structure for premium wall-mounted projection.

Need Help Matching Screen Size and Room Layout?

Confirm wall width, seating distance, projector throw ratio, and installation height before choosing the final screen size.

Project Inquiry →

Dimension Diagram

Frame & Viewing Area Reference

Use with Quick Size Reference below
SCREENPRO Fixed Frame Screen Ultra Thin dimension diagram

Quick Size Reference

Core viewing size, overall dimensions, and weight for quick room planning.

Swipe left to view full specifications →
Format Diag. Size Viewing Size Overall Length Overall Height Weight
16:9 100″ 2213×1245 2229 1260 14.0 KG
16:9 120″ 2656×1494 2671 1509 16.4 KG
16:9 150″ 3320×1867 3335 1883 26.1 KG
16:9 200″ 4427×2490 4442 2505 35.5 KG
16:10 120″ 2584×1615 2600 1630 17.2 KG
2.35:1 150″ 3505×1491 3521 1507 24.4 KG
Quick Planning Note:

This table is intended for fast screen size comparison. For packaging dimensions, T value, and project-level installation data, open the full engineering specifications below.

Engineering & Installation

Need Full Engineering Specs?

View detailed package dimensions, frame reference, T value, and project-level specifications for AV integrators, dealers, and custom installation planning.

Full Engineering Specs

Complete dimension reference for SCREENPRO Fixed Frame Screen - Ultra Thin.

Swipe left to view full engineering specifications →
Format Diag. Size Viewing Size
WxH
Overall Length Overall Height T Package
W1×H1×L1
Weight
16:9 100″ 2213×1245 2229 1260 540 270×140×1385 14.0 KG
16:9 106″ 2346×1319 2361 1335 577 270×140×1459 14.7 KG
16:9 110″ 2434×1369 2450 1385 602 270×140×1509 15.3 KG
16:9 120″ 2656×1494 2671 1509 665 270×140×1635 16.4 KG
16:9 135″ 2988×1680 3003 1696 745 270×140×1825 23.4 KG
16:9 150″ 3320×1867 3335 1883 838 270×140×2010 26.1 KG
16:9 160″ 3541×1992 3557 2007 932 270×140×2135 28.9 KG
16:9 180″ 3984×2241 3999 2256 1025 270×140×2385 31.7 KG
16:9 200″ 4427×2490 4442 2505 1150 270×140×2630 35.5 KG
16:9 220″ 4869×2739 4885 2754 1274 270×140×2885 39.5 KG
16:9 250″ 5534×3112 5549 3128 1460 270×140×3260 45.7 KG
16:9 300″ 6640×3735 6656 3750 1772 270×140×3880 56.5 KG
16:10 100″ 2153×1346 2169 1361 590 270×140×1490 14.4 KG
16:10 106″ 2283×1426 2298 1442 630 270×140×1570 15.2 KG
16:10 110″ 2369×1480 2384 1496 658 270×140×1625 15.8 KG
16:10 120″ 2584×1615 2600 1630 725 270×140×1760 17.2 KG
16:10 135″ 2907×1817 2923 1832 826 270×140×1960 24.2 KG
16:10 150″ 3230×2019 3246 2034 927 270×140×2165 27.0 KG
16:10 160″ 3446×2153 3461 2169 995 270×140×2300 28.9 KG
16:10 180″ 3877×2423 3892 2438 1130 270×140×2570 32.7 KG
16:10 200″ 4307×2692 4323 2707 1265 270×140×2840 36.7 KG
16:10 220″ 4738×2961 4754 2977 1398 270×140×3105 40.8 KG
16:10 250″ 5384×3365 5400 3381 1600 270×140×3510 47.2 KG
16:10 300″ 6461×4038 6477 4054 1937 270×140×4185 58.5 KG
2.35:1 100″ 2337×994 2352 1010 415 270×140×1315 13.6 KG
2.35:1 106″ 2477×1054 2493 1069 445 270×140×1385 14.3 KG
2.35:1 119″ 2781×1183 2796 1199 510 270×140×1535 16.0 KG
2.35:1 126″ 2945×1253 2960 1268 545 270×140×1620 16.9 KG
2.35:1 135″ 3155×1342 3170 1358 590 270×140×1725 22.5 KG
2.35:1 150″ 3505×1491 3521 1507 663 270×140×1900 24.4 KG
2.35:1 165″ 3856×1641 3872 1656 738 270×140×2075 26.9 KG
2.35:1 180″ 4207×1790 4222 1805 813 270×140×2250 29.5 KG
2.35:1 200″ 4674×1989 4690 2004 912 270×140×2485 33.0 KG
2.35:1 250″ 5843×2486 5858 2501 1160 270×140×3065 42.2 KG
2.35:1 300″ 7011×2983 7027 2999 1410 270×140×3650 52.0 KG
2.35:1 350″ 8180×3481 8196 3496 1658 270×140×4240 62.5 KG

Plan Your Screen Size Before Inquiry

Use the SCREENPRO Projection Screen Size Calculator to estimate viewing distance, screen dimensions, and projector throw compatibility before selecting your final screen.

Open Size Calculator →
Screen Material

Ambient Light Rejecting ALR Material for Standard Throw Projectors

SCREENPRO® ALR material is designed for long throw and standard throw projection in spaces with ambient light. Its reflective optical surface helps improve image brightness, contrast, and color performance while maintaining a wide viewing area for home theater, conference, and commercial display applications.

SCREENPRO ambient light rejecting ALR screen material for standard throw projector

Optimized for Long / Normal Throw Projection

This ALR screen surface uses a photoelectric composite structure to reject unwanted ambient light while reflecting the projector image toward the audience. It helps deliver clear images, stronger contrast, and vivid color reproduction for 4K and 8K projection systems.

1.1 Screen Gain
160° Wide Viewing Angle
8K Resolution Ready
ALR Ambient Light Rejecting
Explore ALR Material
Used in SCREENPRO® long throw / standard throw ALR screen systems. For full material structure, optical specifications, cleaning instructions, and comparison details, please visit the dedicated ALR material page.



SCREENPRO ALR SYSTEM

Same ALR Material, Different Screen Styles

Prefer the same long-throw ALR viewing performance, but need a different installation style? Explore SCREENPRO ALR screen formats for motorized, floor-rising, in-ceiling and fixed-frame applications.

Long Throw ALR Motorized Floor Rising In-Ceiling Fixed Frame
TJ

Tab-Tensioned Motorized ALR Screen

Model TJ-8K

Premium motorized ALR screen with tab-tensioned flatness, designed for long or normal throw projectors in bright home theater spaces.

Motorized Tab-Tension
View Product →
TD

Self-Rising ALR Screen

Model TD-8K

Floor-rising ALR solution for rooms where wall or ceiling mounting is not preferred. Ideal for flexible living room cinema setups.

Floor Rising Living Room
View Product →
TI

In-Ceiling ALR Screen

Model TI-8K

Recessed ceiling ALR screen format for architectural projects that require a clean hidden installation when the screen is not in use.

Hidden Install Ceiling Recessed
View Product →
FZ

7mm Fixed Frame ALR Screen

Model FZ-8K

Ultra-slim fixed frame ALR screen with a clean 7mm visual edge, suitable for dedicated cinema rooms and premium interior projects.

Fixed Frame Ultra Slim
View Product →
FP

Fixed Frame ALR Screen

Model FP-8K

Classic fixed-frame ALR screen format for permanent installations where maximum screen stability and a theater-style appearance are required.

Permanent Install Cinema Room
View Product →

Need the same ALR performance in another installation style?

Tell us your projector type, room lighting and installation method. SCREENPRO will help match the right ALR screen structure for your project.

COMPLETE YOUR SCREENPRO SYSTEM

Compatible Accessories & Installation Solutions

Universal ceiling projector mount bracket compatible with Epson Yaber HAPPRUN TMY and most projectors

Universal Projector Mount Bracket

Inch-screw compatible ceiling bracket for Epson, Yaber, HAPPRUN, TMY and most standard projectors.

SCREENPRO projector ceiling mount for home theater installation

Projector Ceiling Mount

Stable ceiling mounting solution for projector installation in home theater, meeting room and commercial spaces.

SCREENPRO Fully Concealed Ceiling ALR Screen - Ti-8K
SCREENPRO Fully Concealed Ceiling ALR Screen - Ti-8K
SCREENPRO Fully Concealed Ceiling ALR Screen - Ti-8K
Application
Home Theater, Conference room etc.
Home Theater, Conference room etc.
Home Theater, Conference room etc.
Installation
Suspending | Wall Mount | Ceiling Mount
Suspending | Wall Mount | Ceiling Mount
Suspending | Wall Mount | Ceiling Mount
Ceiling Projector
Expansion Port
RS485/RS232、DC AMX
RS485/RS232、DC AMX
RS485/RS232、DC AMX
Limit Adjustment
Remote
Remote
Remote
Control Options
868MHz IR remote
868MHz IR remote
868MHz IR remote
Low Voltage Trigger
Optional
Optional
Optional
Color Options
White
White
White
Available Sizes
100-150 Inch
100-150 Inch
100-150 Inch
Motor
E-Limit Tubular Motor
E-Limit Tubular Motor
E-Limit Tubular Motor
Housing
Steel
Steel
Steel
SCREENPRO architectural projection screen solutions for home cinema, ALR, acoustic transparent and commercial applications

Frequently Asked Questions

Everything you may want to know before choosing a SCREENPRO® projection screen.

The ideal screen material depends on your projector type, room lighting, and installation environment.

  • UST projector → UST ALR screen material
  • RGB triple laser projector → 3C or 3W anti-speckle material
  • Standard throw projector → white screen or long throw ALR material
  • Dedicated theater → acoustic transparent screen material

If you are unsure, SCREENPRO can recommend a suitable projection screen solution based on your projector model and room layout.

A standard white screen is best for dark or controlled lighting rooms. An ALR screen is designed to reduce the influence of ambient light and improve perceived contrast in brighter environments.

  • White screen → best for dark rooms
  • ALR screen → better contrast with ambient light
  • UST ALR screen → designed for ultra short throw projectors
  • Long throw ALR screen → designed for standard or long throw projectors

The best screen for contrast depends on your projector type and room lighting. In dark rooms, a high-quality white or acoustic transparent screen can deliver natural contrast. In rooms with ambient light, ALR screen materials help maintain deeper blacks and stronger perceived contrast.

  • UST projector → UST ALR screen
  • Standard throw projector → Long throw ALR screen
  • RGB triple laser projector → 3C or 3W anti-speckle material
  • Dedicated cinema room → White or acoustic transparent screen

For RGB triple laser projectors, SCREENPRO recommends 3C Anti-Speckle or 3W Woven Anti-Speckle materials. These materials are designed to reduce laser speckle while preserving image contrast, color performance and viewing comfort.

Technically yes, but a dedicated UST ALR screen usually provides better image performance. UST projectors project light from a steep angle, so a normal screen may show lower contrast, uneven brightness or visible texture depending on the material.

Screen size should be selected according to viewing distance, room size, projector brightness and installation space.

  • 8–10 ft viewing distance → 100"–120"
  • 10–12 ft viewing distance → 120"–135"
  • 12–15 ft viewing distance → 135"–150"

For commercial, church, education or large venue applications, custom screen size recommendations may be required.

  • 3C → balanced anti-speckle performance for RGB laser projectors
  • 3W → stronger anti-speckle performance with woven acoustic transparency

3C is suitable for many triple laser projection setups, while 3W is recommended when stronger speckle reduction and acoustic transparency are required.

Most SCREENPRO® floor-rising screens are designed as freestanding systems and do not require wall fixation for normal use. For special installations, wall brackets or additional securing methods may be recommended depending on the environment.

Temporary waves or wrinkles may be caused by transportation, temperature changes, humidity, storage conditions or installation tension. Tab-tensioned and fixed frame structures generally provide better long-term flatness than non-tensioned or folding screen systems.

Many SCREENPRO motorized projection screens support RF remote control, 12V trigger, USB trigger, RS232, Tuya Smart, Alexa and Google Assistant integration. Compatibility may vary depending on the motor and control system selected.

Yes. Material samples are available for testing before purchasing a complete screen system. Samples can help you compare brightness, contrast, texture, acoustic transparency and anti-speckle performance in your own environment.

Yes. SCREENPRO supports customized screen sizes depending on the screen type, material, aspect ratio and application requirements. Custom options are commonly used for home cinema, commercial spaces, conference rooms, churches and OEM/ODM projects.

Warranty coverage varies by product category. Motorized systems, projection surfaces and accessories are covered under SCREENPRO warranty policies. Please contact SCREENPRO for specific warranty details based on your product model and installation type.
