【For Long-focus/Normal-throw Laser Projectors】
A new way to open your private home theater in seconds. Unboxing to operate, no need to install it, you can move it at will. SCREENPRO self-rising screen supports floor mount style, hidden in a variety of display ways, with no more drilling in the wall, multi-voltages, and plugs applicable.
*perforated black border upon request
The micro-perforations on the ALR fabric are so small that they are nearly unnoticeable to the naked eye, and completely invisible when your projector is on, greatly reducing the problem of light loss. Audio waves coming from your speakers can easily pass through, making for a surround sound acoustically transparent screen and the best image resolution you’ve ever seen.
This means you don’t have to compromise with the image or sound. Compared to the standard fabric, SCREENPRO 8K has a much better effect from the perspective of contrast, brightness, and resolution.
If you don't want a fixed frame screen or ceiling mount electric screen, then the electric ALR floor screen will be the ideal option, a screen that rises from the ground. A freestanding projector screen is an ideal solution when wall or ceiling installations are impractical for the common roll-up projector screen. The screen has a high-density, hardcore military design, which requires no punching or installation. Connect to the power cord for quick use. This Tab-tensioned floor screen is the ideal solution for this demand.
At a generous viewing angle, everyone in the room gets the best seat in the house and enjoys the family movie night or game night with the crowd.
Duo V-shaped Arm With Unique Spherical Bearing. The ground-rising structure coordinates with a silent tubular motor that drives a double V-shaped structure bracket, with uniform force, to avoid stretching deformation of the fabric. The quiet tubular motor, which has UL, CE, and 3C certifications, operates smoothly with low noise.
Simple seamless design with angular appearance, without too many line modifications, easy to clean
Withstanding screen structure gives you more diversity in home decor and automation.
SCREENPRO’s D series motorized screen lets you quickly lower or raise your projection surface with a simple button press for ultimate viewing convenience. The sleek, space-saving design can add a modern touch to any living space by positioning your screen neatly out of the way.
At SCREENPRO, we discover and produce a wide range of premium materials for you to choose from, to respond to different application sites and projection environments.
Go ahead and project on a fabric sample first. If you have any questions, we are here to help.
| SHOP NOW |
We send packages overseas, wrapping your screen to avoid it being damaged securely. The inner layer of the carton package is pearl cotton and a foam board buffer layer. A customized solid wood outer frame ensures the product is delivered to your home in good condition.
You can chill and relax waiting for it to appear at your door.
SCREENPRO Size Chart Pro Ultra
The SCREENPRO® TD-T8 floor rising projection screen is designed for long throw projection, ALR performance, and acoustic transparent home cinema installations. Compare viewing size, black border, screen body dimensions, package dimensions, wooden crate packaging, and project-level specifications before planning your AV installation.
Confirm screen size, projector throw distance, viewing distance, speaker placement, package dimensions, and installation clearance before final project quotation.
Dimension Reference
Use the reference images together with the specification table to confirm viewing size, black border, screen body size, package size, and logistics planning.
Core viewing size, overall dimensions, and weight for fast TD-T8 model comparison.
| Format | Diag. Size | Viewing Size | Overall Length | Overall Height | Weight |
|---|---|---|---|---|---|
| 16:9 | 92" | 2037 × 1145 mm | 2272 mm | 1578 mm | 32 kg / 70 lbs |
| 16:9 | 100" | 2214 × 1245 mm | 2449 mm | 1680 mm | 33 kg / 73 lbs |
| 16:9 | 110" | 2435 × 1370 mm | 2670 mm | 1805 mm | 36 kg / 79 lbs |
| 16:9 | 120" | 2656 × 1494 mm | 2891 mm | 1929 mm | 38 kg / 84 lbs |
| 16:9 | 135" | 2988 × 1681 mm | 3223 mm | 2116 mm | 42 kg / 92 lbs |
| 16:9 | 150" | 3320 × 1868 mm | 3555 mm | 2253 mm | 46 kg / 100 lbs |
| 16:10 | 92" | 1982 × 1239 mm | 2227 mm | 1674 mm | 31 kg / 69 lbs |
| 16:10 | 100" | 2154 × 1346 mm | 2399 mm | 1681 mm | 33 kg / 73 lbs |
| 16:10 | 106" | 2283 × 1427 mm | 2528 mm | 1762 mm | 35 kg / 76 lbs |
| 16:10 | 110" | 2369 × 1481 mm | 2614 mm | 1816 mm | 36 kg / 78 lbs |
| 16:10 | 120" | 2585 × 1615 mm | 2830 mm | 1950 mm | 38 kg / 83 lbs |
| 16:10 | 135" | 2908 × 1817 mm | 3153 mm | 2152 mm | 41 kg / 91 lbs |
| 16:10 | 144" | 3231 × 2019 mm | 3476 mm | 2225 mm | 44 kg / 96 lbs |
| 2.35:1 | 96" | 2244 × 955 mm | 2489 mm | 1390 mm | 34 kg / 74 lbs |
| 2.35:1 | 100" | 2337 × 995 mm | 2582 mm | 1430 mm | 35 kg / 77 lbs |
| 2.35:1 | 106" | 2478 × 1054 mm | 2723 mm | 1489 mm | 36 kg / 80 lbs |
| 2.35:1 | 119" | 2781 × 1184 mm | 3026 mm | 1619 mm | 40 kg / 87 lbs |
| 2.35:1 | 126" | 2945 × 1253 mm | 3190 mm | 1688 mm | 41 kg / 91 lbs |
| 2.35:1 | 135" | 3155 × 1343 mm | 3400 mm | 1778 mm | 44 kg / 96 lbs |
Engineering & Installation
View detailed TD-T8 project specifications, including black border, screen overall size, package dimensions, wooden crate packaging, and approximate weight.
Detailed project-level dimensions for SCREENPRO TD-T8 Floor Rising ALR Acoustic Transparent Screen.
| Format | Diag. Size | Viewing Size | Top Border | Bottom Border | L/R Border | Overall Length | Overall Height | Package Dimensions | Wooden Crate Packaging | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16:9 | 92" | 2037 × 1145 mm | 35 mm | 400 mm | 55 mm | 2272 mm | 1578 mm | 2332 × 235 × 235 mm | 2362 × 250 × 385 mm | 32 kg | 70 lbs |
| 16:9 | 100" | 2214 × 1245 mm | 35 mm | 400 mm | 55 mm | 2449 mm | 1680 mm | 2509 × 235 × 235 mm | 2539 × 250 × 385 mm | 33 kg | 73 lbs |
| 16:9 | 110" | 2435 × 1370 mm | 35 mm | 400 mm | 55 mm | 2670 mm | 1805 mm | 2730 × 235 × 235 mm | 2760 × 250 × 385 mm | 36 kg | 79 lbs |
| 16:9 | 120" | 2656 × 1494 mm | 35 mm | 400 mm | 55 mm | 2891 mm | 1929 mm | 2951 × 235 × 235 mm | 2981 × 250 × 385 mm | 38 kg | 84 lbs |
| 16:9 | 135" | 2988 × 1681 mm | 35 mm | 350 mm | 55 mm | 3223 mm | 2116 mm | 3283 × 235 × 235 mm | 3313 × 250 × 385 mm | 42 kg | 92 lbs |
| 16:9 | 150" | 3320 × 1868 mm | 35 mm | 300 mm | 55 mm | 3555 mm | 2253 mm | 3615 × 235 × 235 mm | 3645 × 250 × 385 mm | 46 kg | 100 lbs |
| 16:10 | 92" | 1982 × 1239 mm | 35 mm | 400 mm | 55 mm | 2227 mm | 1674 mm | 2287 × 235 × 235 mm | 2317 × 250 × 385 mm | 31 kg | 69 lbs |
| 16:10 | 100" | 2154 × 1346 mm | 35 mm | 300 mm | 55 mm | 2399 mm | 1681 mm | 2459 × 235 × 235 mm | 2489 × 250 × 385 mm | 33 kg | 73 lbs |
| 16:10 | 106" | 2283 × 1427 mm | 35 mm | 300 mm | 55 mm | 2528 mm | 1762 mm | 2588 × 235 × 235 mm | 2618 × 250 × 385 mm | 35 kg | 76 lbs |
| 16:10 | 110" | 2369 × 1481 mm | 35 mm | 300 mm | 55 mm | 2614 mm | 1816 mm | 2674 × 235 × 235 mm | 2704 × 250 × 385 mm | 36 kg | 78 lbs |
| 16:10 | 120" | 2585 × 1615 mm | 35 mm | 300 mm | 55 mm | 2830 mm | 1950 mm | 2890 × 235 × 235 mm | 2920 × 250 × 385 mm | 38 kg | 83 lbs |
| 16:10 | 135" | 2908 × 1817 mm | 35 mm | 300 mm | 55 mm | 3153 mm | 2152 mm | 3213 × 235 × 235 mm | 3243 × 250 × 385 mm | 41 kg | 91 lbs |
| 16:10 | 144" | 3231 × 2019 mm | 35 mm | 250 mm | 55 mm | 3476 mm | 2225 mm | 3407 × 235 × 235 mm | 3437 × 250 × 385 mm | 44 kg | 96 lbs |
| 2.35:1 | 96" | 2244 × 955 mm | 35 mm | 400 mm | 55 mm | 2489 mm | 1390 mm | 2549 × 235 × 235 mm | 2579 × 250 × 385 mm | 34 kg | 74 lbs |
| 2.35:1 | 100" | 2337 × 995 mm | 35 mm | 400 mm | 55 mm | 2582 mm | 1430 mm | 2642 × 235 × 235 mm | 2672 × 250 × 385 mm | 35 kg | 77 lbs |
| 2.35:1 | 106" | 2478 × 1054 mm | 35 mm | 400 mm | 55 mm | 2723 mm | 1489 mm | 2783 × 235 × 235 mm | 2813 × 250 × 385 mm | 36 kg | 80 lbs |
| 2.35:1 | 119" | 2781 × 1184 mm | 35 mm | 400 mm | 55 mm | 3026 mm | 1619 mm | 3086 × 235 × 235 mm | 3116 × 250 × 385 mm | 40 kg | 87 lbs |
| 2.35:1 | 126" | 2945 × 1253 mm | 35 mm | 400 mm | 55 mm | 3190 mm | 1688 mm | 3250 × 235 × 235 mm | 3280 × 250 × 385 mm | 41 kg | 91 lbs |
| 2.35:1 | 135" | 3155 × 1343 mm | 35 mm | 400 mm | 55 mm | 3400 mm | 1778 mm | 3460 × 235 × 235 mm | 3490 × 250 × 385 mm | 44 kg | 96 lbs |
SCREENPRO supports ALR acoustic transparent screen planning, floor rising screen project quotation, custom size recommendations, and OEM / ODM customization for dealers, AV integrators, and home theater projects.
Explore compatible SCREENPRO screen materials for various projection environments, including matte white, acoustic transparent, ALR, anti-speckle, and rear-projection applications.
Matte white screen material for standard projection and natural color reproduction.
Micro-perforated acoustic transparent material for speaker-behind-screen setups.
Woven acoustic transparent fabric for natural sound transmission and reduced moiré effect.
Woven acoustic transparent anti-speckle material for RGB triple laser and hidden speaker setups.
High-contrast ALR material for long-throw projection and enhanced black levels.
ALR micro-perforated material for long-throw projection with acoustic transparency.
Anti-speckle grey projection fabric for RGB triple laser projectors with enhanced contrast.
Rear projection material for hidden projector installations and special display applications.
Prefer the same long-throw ALR viewing performance, but need a different installation style? Explore SCREENPRO ALR screen formats for motorized, floor-rising, in-ceiling and fixed-frame applications.
Premium motorized ALR screen with tab-tensioned flatness, designed for long or normal throw projectors in bright home theater spaces.
View Product →Floor-rising ALR solution for rooms where wall or ceiling mounting is not preferred. Ideal for flexible living room cinema setups.
View Product →Recessed ceiling ALR screen format for architectural projects that require a clean hidden installation when the screen is not in use.
View Product →Ultra-slim fixed frame ALR screen with a clean 7mm visual edge, suitable for dedicated cinema rooms and premium interior projects.
View Product →Classic fixed-frame ALR screen format for permanent installations where maximum screen stability and a theater-style appearance are required.
View Product →Tell us your projector type, room lighting and installation method. SCREENPRO will help match the right ALR screen structure for your project.
Adjustable ceiling mounting solution for projector alignment and clean installation layouts.
Automatically raise or lower your SCREENPRO motorized screen when the projector powers on or off.
Install floor-rising projector screens behind cabinets or directly against the wall for cleaner layouts.
Everything you may want to know before choosing a SCREENPRO® projection screen.
No. ALR materials are not recommended for the Quick-Fold series because folding the screen may create creases in the material.
Yes. You can purchase a screen material sample here: Material Sample.
No. SCREENPRO motorized screens are designed for direct plug-and-play operation and do not require a separate external power box or transformer..
Yes. Wall-mounting brackets are included with the wall-mounted screen series..
Yes. SCREENPRO prepares the appropriate voltage and regional power plug based on the shipping destination..
For a primarily nighttime viewing setup, we generally recommend a high-contrast grey screen or an ALR screen, depending on your projector type and room lighting conditions.
Since the screen will retract in front of your OLED TV during projector use, a motorized drop-down or floor-rising screen setup would work well with your room configuration.
SCREENPRO motorized screens are available in 110V / 220V. No power transformer is required. We will ensure the correct voltage is supplied according to your shipping address.
SCREENPRO® mainly produces motorized projection screens, tensioned projection screens, fixed-frame screens, portable folding screens, large-sized stage projection screens, and customized projection solutions.
For project requirements, please contact us.
Yes. SCREENPRO supports customized screen sizes from 60 inches to 500 inches and above, depending on the screen type, material, and installation requirements.
Please contact us for custom sizing.
SCREENPRO specializes in projection screens, motorized screen solutions, theater supplies, projection systems, audiovisual accessories, ALR UST screens, electric screens, manual screens, mobile screens, fixed-frame screens, in-ceiling screens, and customized projection solutions.
We support air transport, sea transport, road transport, rail transport, mail transport, and other shipping methods depending on the destination and order requirements.
For most international orders, we may ship via DHL, FedEx, UPS, TNT, or other suitable carriers. For large-size or project orders, air freight or sea freight can also be arranged.
